Ibis Ripmo V3 XT With Blackbird Send Wheels
Details
IBIS Carbon Ripmo V3 Now Gets Upgrade to OneUp V2 35mm Rise Carbon Bar For FREE!!!
SM/MD size bikes come automatically stock with 29/27.5 setup. XM/LG/XL come stock 29/29.
If there is a wheelset choice you prefer that isn't stock please mention at checkout or stock option is how it will be built. There is no upcharge for doing this.
The Ripmo isn't just a bike; it's a legend.
With multiple "Best in Test" awards and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail-slaying machine. How do you improve on that?
The Ripmo is loaded with new features: internal downtube storage, a flip chip for mixed wheels, a slacker head angle, and increased coil compatibility. We've also expanded our sizing options and added size-specific details—right down to the bottom bracket height.
Wheel size:
Sizes Small – Medium: 29-inch front / 27.5-inch rear
Sizes Medium/Large – X-Large: 29-inch
*Specs may vary from image displayed*
| Frame Size | Small | Medium | Extra Medium | Large | X-Large |
|---|---|---|---|---|---|
| Seat Tube (mm) | 395 | 400 | 415 | 457 | 477 |
| Top Tube (mm) | 578 | 605 | 630 | 655 | 685 |
| Head Tube (mm) | 85 | 95 | 110 | 125 | 140 |
| Chainstay (mm) | 435 | 435 | 436 | 438 | 440 |
| Seat Tube Angle | 77° | 76.5° | 76.5° | 77° | 77.5° |
| Saddle Height For Seat Tube Angle (mm) | 650 | 700 | 745 | 790 | 830 |
| Head Tube Angle | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° |
| Wheelbase (mm) | 1195 | 1219 | 1249 | 1286 | 1329 |
| Stack (mm) | 616 | 622 | 633 | 643 | 654 |
| Reach (mm) | 436 | 456 | 478 | 506 | 540 |
| BB Drop (mm) | 36 | 33 | 30 | 27 | 24 |
| BB Height (mm) | 338 | 341 | 344 | 349 | 350 |
| Standover (mm) | 693 | 734 | 757 | 772 | 784 |
| Recommended Seatpost Drop (mm) | 140 | 170 | 185 | 213 | 213 |
| Crank Length (mm) | 165 | 165 | 170 | 170 | 170 |
Specs
| Pedals | Sold Separately |
|---|---|
| Fork | Fox Float 36 Factory Series Grip X 160mm, 29”, 110x15 |
| Hubs |
Front Hub Ibis Logo Front Hub, 110x15, 32 Hole Rear Hub Ibis Logo Rear Hub, 148x12, 32 Hole |
| Rims | Ibis Blackbird Send Alloy, 32 hole, 29" XM -> XL, Ibis Send Alloy, 32 hole, 27.5" S & M |
| Stem | BLKBRD 35 Stem S–M: 35mm, XM–XL: 50mm |
| Chain | Shimano XT M8100 |
| Frame | Ripmo V3 |
| Tires |
Front Tire: Maxxis DHF2, 29”x 2.5”, Exo+ Rear Tire: Maxxis DHR, 27.5” x 2.5” |
| Brakes | Shimano XT M8120 4p |
| Rotors | Shimano SM-RT86 180 |
| Saddle | WTB Silverado Fusion 142 |
| Spokes | Sapim Dlight Double Butted |
| Wheels | Send I 29 Alloy Front Wheel 110, Send II 29 Alloy Rear Wheel 148 MS |
| Headset | Cane Creek 40: ZS44/ZS56 |
| Crankset | Shimano XT M8100 24mm spindle |
| Seatpost | Oneup V3 120 SM, 150 MD, 180 XM, 210 LG/XL |
| Shifters | Shimano XT M8100 |
| Handlebars | OneUp V2 35mm Rise Carbon Bar (Free Upgrade) |
| Rear Shock | Fox Float X Factory Series, 2 Pos Adj with EVOL, 230 x 60 |
| Tape/Grips | Lizard Skin Charger |
| Brake Levers | Shimano XT M8120 |
| Bottom Bracket | Shimano XT MT800 |
| Rear Derailleur | Shimano XT M8100 Shadow Plus |
| Accessories & Extras | Cotopaxi Stow Bags |
| Cassette/Freewheel | Shimano XT 10-51 |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Heckleberry Purple / Small / 29-inch front / 27.5-inch rear | 840345309976 | RMC1PRSXTAL3525 | 210000022027 |
| Heckleberry Purple / Large / 29-inch | 840345310453 | RMC4PRSXTAL3525 | 210000022081 |
| Heckleberry Purple / Medium/Large / 29-inch | 840345310293 | RMC3PRSXTAL3525 | 210000022063 |
| Swamp Monster / Medium / 29-inch front / 27.5-inch rear | 840345310057 | RMC2OLSXTAL3525 | 210000022054 |
| Heckleberry Purple / X-Large / 29-inch | 840345310613 | RMC5PRSXTAL3525 | 210000022099 |
| Swamp Monster / Large / 29-inch | 840345310378 | RMC4OLSXTAL3525 | 210000022090 |
| Heckleberry Purple / Medium / 29-inch front / 27.5-inch rear | 840345310132 | RMC2PRSXTAL3525 | 210000022045 |
| Swamp Monster / Small / 29-inch front / 27.5-inch rear | 840345309891 | RMC1OLSXTAL3525 | 210000022036 |
| Swamp Monster / Medium/Large / 29-inch | 840345310217 | RMC3OLSXTAL3525 | 210000022072 |
